Pendulum jigsaw PSTK 800 D3, 800 W

Description

No-load speed: 0-3100 rpm
Cutting angle (left/right): 0°/22.5°/45°

✓ SAW LOCK quick-release chuck for easy blade changes
✓ Blower function for a chip-free cutting line
✓ Ergonomic handle with non-slip coating

PARKSIDE® Pendulum Jigsaw PSTK 800 D3, 800 W

Features

• Fast cutting progress with adjustable 3-level pendulum stroke
• Fine cutting mode without pendulum stroke
• Laser guide and LED work light
• Ergonomic handle with non-slip rubber coating
• Electronically adjustable stroke rate
• Tool-free adjustable baseplate with cutting angles adjustable on both sides
• Blower function for a chip-free cutting line
• External dust extraction connection – includes dust extraction tube with reducer
• SAW LOCK quick-release chuck for easy blade changes
• Transparent blade guard
• Chip splinter guard
• Compatible with single-hook shank saw blades
• Includes carrying case

Included Accessories:

• 1x wood saw blade
• 1x metal saw blade
• 1x parallel guide
• 1x external dust extraction adapter with reducer (pre-installed)

Technical Specifications

• Power: 800 W
• No-load speed: 0-3100 rpm
• Pendulum motion: 3 positions + fine cutting mode
• Stroke length: 26 mm
• Maximum cutting depth:
  • 80 mm in wood
  • 12 mm in aluminum
  • 8 mm in metal
• Cutting angle (left/right): 0°/22.5°/45°
• Tool-free angle adjustment
• Guidance assistance: laser and parallel guide
• Sound pressure level (LpA): 95 dB (A)
• Sound power level (LWA): 106 dB (A)
• Total vibration value (wood cutting): 6.8 m/s²
• Total vibration value (metal cutting): 7.2 m/s²

Materials

• Plastic, fiberglass

Dimensions

• Jigsaw: approx. 26.9 x 19 x 7.4 cm
• Parallel guide: approx. 21.8 x 6.8 x 2.49 cm
• Saw blade (wood): approx. 10 x 0.8 cm
• Saw blade (metal): approx. 7.64 x 0.8 cm
• Dust extraction adapter: approx. Ø 3.5 x 4.4 x Ø 3.6 cm

Weight

• Approx. 2.4 kg
